Automatic Paper Jam Laminating Machine

Machine Introduction

The HCBK-1080 fully automatic cardboard laminating machine uses a PLC controlled Feida conveyor for the top and bottom paper, ensuring a smooth and accurate paper feeding process. The adhesive part on the base paper adjusts the amount of adhesive applied without stopping the machine according to the requirements of different papers, improving work efficiency. The base paper and surface paper are simultaneously positioned by the side pull gauge and enter the composite roller for laminating. After initial pressing, they are output through multiple hydraulic pressing rollers, and the finished product enters the paper delivery machine.

The card mounting machine is controlled by PLC program, equipped with multiple pressure rollers, and automatically controls the hydraulic station. The finished product has high bonding accuracy, and the base paper and surface paper are firmly and smoothly laminated. The finished product immediately enters the next process without waiting. Automated production, enhanced production processes, shortened process time, improved work efficiency, reduced production costs, and created benefits for enterprises.

Machine features

1. High strength gravity bearing is selected for the main key parts.

2. The host base and wall panels are made of high-quality materials.

3. The laminating roller and pressure roller undergo heat treatment and hard chrome plating to enhance their pressure resistance and make them difficult to deform.

4. The pressure roller is controlled by an automatic hydraulic system for compression, ensuring stable pressure and a firm, smooth, and aesthetically pleasing product fit.

5. The transmission part of the main engine adopts gear transmission, and the gears that have undergone heat treatment are not easily worn.

6. Humanized human-machine dialogue interface, combined with PLC programmable controller, makes the operation of the machine simple, convenient, reliable, and accurate.

7. Automatic glue supply system ensures uniform glue supply and stable glue volume, allowing finished products to enter the next process without waiting for drying time.

8. The Feida paper feeder adopts a pre stacking mechanism to improve work efficiency.

We Can Meet The Needs of Wide Application of Various Products
